Apply a texture image

Goal: cover a ground plane with a checkerboard image, and repeat a wood image on a shape.

Starting point: the default project template (src/scene.hpp, src/scene.cpp, see Your first scene). It already declares the shapes sphere and cylinder, a timer, and the members camera_control, environment and gui: reuse them, do not declare them again. The first comment of each code block says in which file and where its lines go: add means insert them, replace means replace the whole function by the one shown.

Interactive CGP demo (apply-a-texture). Open in a new tab.

How the image is mapped

Each vertex of a mesh has a texture coordinate uv in [0,1]^2: (0,0) is the bottom-left corner of the image and (1,1) the top-right corner. The default shader reads the image color at the interpolated uv of each pixel and multiplies it by the vertex color and by material.color.

Initializing a texture copies an image_structure to GPU memory and keeps its id and size; on a quad, uv runs from (0,0) to (1,1) and the default shader reads (u, 1-v), so the first row of the file shows at the top. Tap to enlarge.

The mesh_primitive_* functions and mesh_load_file_obj already fill uv. For a mesh built by hand, see Build a mesh by hand.

1. Put the image in the project

The template has no image. Download the two images used on this page:


Create a folder assets/ at the root of the project, next to shaders/ and src/, and save the images in it: assets/checkerboard.png and assets/wood.jpg. Any PNG or JPEG image works the same way.

2. Declare the drawable

// scene.hpp - add in scene_structure
mesh_drawable ground;

3. Create the shape, then load the texture (once)

// scene.cpp - add at the end of initialize()
float const L = 3.0f;
ground.initialize_data_on_gpu(mesh_primitive_quadrangle(
    {-L,-L,-0.5f}, {L,-L,-0.5f}, {L,L,-0.5f}, {-L,L,-0.5f}));

ground.texture.load_and_initialize_texture_2d_on_gpu(project::path + "assets/checkerboard.png");

The ground is placed at z = -0.5, under the sphere and the cylinder of the template (they are centered at z = 0, and the cylinder goes down to z = -0.5).

load_and_initialize_texture_2d_on_gpu reads the file, sends the pixels to the GPU and stores the texture handle in ground.texture. Without it, the drawable uses a default 1x1 white texture, which is why untextured shapes show their plain material.color.

4. Draw (every frame)

// scene.cpp - add in display_frame(), before timer.update()
draw(ground, environment);

Nothing else is needed: draw binds the texture automatically. Expected result: a 6 x 6 square under the red sphere and the green cylinder, covered by one copy of the checkerboard.

Repeat the image: wrap mode

When uv goes beyond [0,1], the wrap mode decides what is displayed. Pass it as the second (s, along u) and third (t, along v) arguments. This code replaces the code of step 3 in initialize() (keep steps 2 and 4): a drawable is initialized only once, and initializing ground a second time prints warnings about non-empty buffers.

// scene.cpp - in initialize(), instead of the code of step 3
// 4 x 4 copies of the image on the ground
float const L = 3.0f;
mesh ground_mesh = mesh_primitive_quadrangle({-L,-L,-0.5f}, {L,-L,-0.5f}, {L,L,-0.5f}, {-L,L,-0.5f});
for (vec2& uv : ground_mesh.uv)
    uv = 4.0f * uv;
ground.initialize_data_on_gpu(ground_mesh);
ground.texture.load_and_initialize_texture_2d_on_gpu(
    project::path + "assets/wood.jpg", GL_REPEAT, GL_REPEAT);

Wrap mode (OpenGL)	Outside `[0,1]`
`GL_CLAMP_TO_EDGE` (default)	the border pixels are stretched
`GL_REPEAT`	the image is tiled
`GL_MIRRORED_REPEAT`	tiled, every other copy mirrored
`GL_CLAMP_TO_BORDER`	a constant border color

With uv beyond [0,1], GL_REPEAT tiles the image, GL_MIRRORED_REPEAT flips every other copy, and GL_CLAMP_TO_EDGE (the default) stretches the edge texels. Tap to enlarge.

Common pitfalls

The program stops with an error on the file name: the image was not found; check the path and that assets/ is at the root of the project (next to shaders/), not in src/ or in the build folder.
The shape has a single uniform color: the mesh has no meaningful uv (all zero), so every pixel reads the same texel. Fill uv when you build the mesh.
The image is upside down: images are stored top row first, so the default shader flips v (material.texture_settings.inverse_v is true by default). Set it to false for a texture that is already flipped, or flip v in the mesh.
The texture looks tinted: the image color is multiplied by material.color; keep it white {1,1,1} to see the image as is.

Variations

Same image on several shapes: load it once into an opengl_texture_image_structure variable and assign it, cube.texture = wood_texture; (only the GPU handle is copied).
Image computed on the CPU (procedural, simulation): initialize_texture_2d_on_gpu takes a grid_2D<vec3> or an image_structure, and update re-sends a modified one at each frame.
Transparent pixels (PNG alpha channel): see Draw transparent objects.

Source: course labs of CSC_43043 (public version, without the solutions): 05_shaders/a_shader_manipulation (checkerboard ground), 07_texture/a_uv_texture (GL_CLAMP_TO_BORDER) and 08_project (palm tree with GL_REPEAT), scene.cpp.
